Emergent Team·May 25, 2026·11 min read

Data Center Metering: PUE, Tenant Submetering & Carbon Compliance

Data centers are among the most energy-intensive building types in the commercial sector, with energy costs frequently exceeding the initial cost of IT hardware over a five-year lifecycle. The average PUE worldwide is 1.56, meaning 36 percent of total data center energy goes to overhead rather than computing. Meanwhile, NYC's Local Law 88 mandates submetering for tenant spaces in buildings over 25,000 square feet, and LL97 carbon caps apply to data centers like any other commercial building. This post explains how Emergent Metering's subcircuit monitoring technology addresses the unique challenges of data center metering.

Why Data Centers Require Specialized Metering

Data centers present metering challenges that differ fundamentally from typical commercial buildings. Unlike an office where HVAC runs on a predictable schedule and lighting follows occupancy, data centers operate 24/7/365 with IT loads that fluctuate based on computing demand rather than weather or occupancy. Cooling systems must respond dynamically to IT heat output. Power distribution involves multiple conversion stages (utility input, UPS, PDU, rack-level) where losses accumulate. And the density of electrical circuits in a data center far exceeds that of any other building type.

PUE (Power Usage Effectiveness) is the primary efficiency metric, calculated as total facility energy divided by IT equipment energy. Measuring PUE accurately requires metering at two distinct points: the total facility input (from the utility or on-site generation) and the IT equipment load (at the output of the UPS or the input to the PDU). The ISO/IEC 30134-2:2026 standard provides guidance on measurement categories and boundary definitions.

Subcircuit Monitoring Architecture for Data Centers

Utility and Main Distribution

PAN-42 three-phase meters at the main utility service entrance capture total facility energy input. Additional PAN-42 meters at each major distribution switchboard (mechanical power, IT power, lighting/general power) disaggregate the facility into its primary load categories. For buildings with redundant utility feeds or on-site generation, each source requires its own PAN-42 to capture the complete energy picture.

UPS and PDU Monitoring

The UPS input/output boundary is the most common PUE measurement point for IT energy. PAN-42 meters on the UPS input and output capture conversion losses. PAN-14 sensors with external CTs on individual PDU feeds to each row or zone provide the granular visibility needed to track IT load distribution. For colocation data centers, these PDU-level meters serve double duty: they provide the tenant-level submetering that LL88 requires while also enabling cabinet-level or cage-level energy allocation for billing.

Cooling Infrastructure

Cooling typically represents 30–50 percent of total data center energy consumption and is the primary target for PUE improvement. PAN-42 meters on each CRAC/CRAH unit, chiller, cooling tower, and pump circuit provide the real-time power data needed to optimize cooling system performance. EES-301 or EES-401 ultrasonic BTU meters on chilled water loops measure the thermal energy delivered, enabling calculation of cooling system COP (coefficient of performance) alongside electrical efficiency.

When the data shows that a particular CRAH unit is consuming more energy per BTU of cooling delivered than its peers, it signals fouled coils, low refrigerant charge, or fan belt slippage. PowerRadar's benchmarking feature can compare identical cooling units side-by-side, normalized for load, to identify underperformers.

Lighting and General Power

Data center lighting (both in data halls and support spaces) and general power represent a small but non-trivial portion of total facility energy. PAN-10 sensors on lighting circuits and PAN-12 sensors on general receptacle panels capture these loads for complete PUE accounting and LL97 carbon emissions calculations.

Real-Time PUE Tracking in PowerRadar

PowerRadar's device group feature allows data center operators to create logical groupings that map directly to PUE components. "Total Facility Energy" includes all metered loads. "IT Equipment Energy" includes UPS output or PDU input meters. PowerRadar calculates PUE continuously as the ratio of these two groups, displaying it on customizable dashboard widgets that show current PUE, trending PUE over time, and comparison against target values.

The Energy Flow (Sankey) diagram shows the complete power cascade from utility input through UPS, PDU, and rack-level distribution, with cooling, lighting, and general power branching off at each stage. The width of each flow represents its energy magnitude, making it immediately visible where the largest overhead losses occur.

Automated PUE reports can be scheduled for weekly or monthly delivery to data center management, ownership, and tenants.

LL97 and LL88 Compliance for NYC Data Centers

NYC data centers face dual compliance obligations. Local Law 97 places carbon caps on the building based on occupancy type and size, with $268 per metric ton penalties for exceeding the cap. Local Law 88 requires submetering for commercial tenant spaces exceeding 10,000 square feet (5,000 square feet in mixed-use buildings) and monthly power-use statements to tenants.

For colocation facilities, LL88 compliance requires tracking energy consumption at the cabinet, cage, or suite level depending on tenant configurations. The Leviton S7100 BCM's 48-input model provides the per-circuit monitoring needed to allocate energy to individual tenants from shared distribution infrastructure. All tenant metering data flows into PowerRadar, which generates the monthly power-use statements LL88 requires.

For LL97, the comprehensive metering infrastructure installed for PUE optimization and tenant billing also provides the data needed to calculate the building's total carbon emissions. PowerRadar's carbon footprint widget applies the appropriate emission factors to the building's total electricity consumption, providing the annual CO2e calculation that LL97 requires.

Operating or planning a data center? Contact Emergent Metering at 215-645-7141 to discuss PUE monitoring, tenant submetering, and carbon compliance solutions.
